Quartz Acid Leaching and Slab-grade Silica Sand Processing Plant in Congo

The raw ore of this project is vein quartz.

In accordance with on-site conditions, senior beneficiation engineer Yang Guoqing completed the overall layout and design of the construction scheme, and selected the most cost-effective equipment combination for the client.

GUOTE SOLUTION

  • 1

    Three-stage Crushing and Acid Leaching Raw vein quartz is treated by three-stage crushing, then delivered to the acid leaching section for impurity removal, followed by drying.

  • 2

    Vertical Sand Making with Airflow Classification Crushed material is lifted by elevator into the vertical sand maker. Adopting the rock-on-rock crushing principle, this process reduces iron contamination and optimizes grain shape. Built-in airflow classification instantly captures fine dust produced by impact crushing. It limits fine fraction loss and dust emission. Unlike conventional horizontal sand makers that generate more than 30% fines, this latest vertical unit controls fine dust content within 5%–10%.

  • 3

    Magnetic Separation Material is fed onto the belt magnetic roller separator. Non-magnetic silica sand falls off directly into the non-magnetic discharge outlet. Magnetic impurities are held by the magnetic roller and carried to the magnetic discharge end, realizing effective separation of magnetic contaminants from silica sand.

  • 4

    Precision Screening Guote customized high-capacity high-precision screening equipment: linear vibrating screens and square gyratory sifters. Driven by vibrators, the screen surface produces compound vibration and gyratory motion. Materials are quickly dispersed on the screen deck to achieve high-efficiency grading.

PROJECT RESULT

Following the principle of investment optimization, Guote adjusted and optimized equipment configuration according to practical production conditions to satisfy all process indexes.

The whole beneficiation line runs steadily with reliable equipment performance. Final beneficiation indicators and economic benefits reach and surpass design targets, with the overall output exceeding the client’s expectation by 5%. The customer is highly satisfied with this turnkey project.

A Quartz Acid Leaching and Slab-grade Silica Sand Processing Plant in Congo
B Quartz Acid Leaching and Slab-grade Silica Sand Processing Plant in Congo
C Quartz Acid Leaching and Slab-grade Silica Sand Processing Plant in Congo
D Quartz Acid Leaching and Slab-grade Silica Sand Processing Plant in Congo
